| Standard
: |
The Equipment will meet the requirement
mentioned in IS, BS, AATCC and
IS Standard Test Method |
| Light
Source : |
500 MBTL (Mercury Ballast) Tungsten
Filament Lamps and internally
Phosphor coated, mounted centrally
so that the light distribution
constant around the Circumference. |
| Working
Life of Lamp : |
2000 hours approx. |
| Exposure
to Samples |
The
Equipment will provide equal exposure
to all samples by a Moving Drum.
|
| Hollow
Cylinder: |
The Equipment will consist of
a Hollow Cylinder of Metal open
at both ends with an internal
dia of 18" |
| Viewing
Glass: |
A Viewing Glass will be fitted
on the Sample Chamber. |
| Hour
Meter with Buzzer : |
An
Hour Meter with Audio-Visual Alarm
and Hour Tantalizer will be mounted
on the Base. |
| Specimen
Card Size : |
110 x 50 mm |
| Specimen
Thickness : |
Upto 15 mm |
| Specimen
Holder : |
04 Specimen Holders installed
at equidistance in the inner Circumference
of Cylinder along with Metal Sheet
mark to cover half of each Test
Specimen and the Standards. |
| Constant
Cooling : |
Water
Tank and Horizontal Pump will
be equipped for Constant Cooling
with water flow when temperature
touches upto 80°C. |
| Test
Tube Holder : |
Test
Tube Holders for Humidity Control
– 50 nos |
| Voltage
Stabilizer : |
01
no |
| Safety
: |
Auto control for Switching off
the Lamp when the temperature
and humidity goes beyond the set
limit. |
| Grey
Scale : |
Grey
Scale Change in Colour will be
provided with the
Equipment (SDC - UK/AATCC - USA). |
| Blue
Wool : |
1-8
Blue Wool Light Fastness Standards
of SDC – UK/AATCC –
USA) will be provided with the
equipment. |
